Stock number: 2084-1079
Technical data
| Spindle diameter 200 mm | |
| Machining width 6000 mm | |
| Machining height 3150 mm | |
| Machining depth max. 1985 mm | |
| More information on the product page |
Description of the
Spindle diameter 200 mm
Machining width 6000 mm
Machining height 3150 mm
Machining depth max. 1985 mm
Sliding cross-section 530 x 550 mm
Table load 20 tonnes
Plattenfeldgröße 11.200 x 5.550 mm
Tool holder SK 60
Total power requirement 83 kW
Machine weight approx. 173 tonnes
- Additional equipment angle head large and small - The OB-No. is: 22979 - The table is model S20 MP Table size: 2200 x 2500 mm - The processing width on the machine X -Way is 6000 mm - Including 6 plates 5600 mm x 1850 mm
Machining width 6000 mm
Machining height 3150 mm
Machining depth max. 1985 mm
Sliding cross-section 530 x 550 mm
Table load 20 tonnes
Plattenfeldgröße 11.200 x 5.550 mm
Tool holder SK 60
Total power requirement 83 kW
Machine weight approx. 173 tonnes
- Additional equipment angle head large and small - The OB-No. is: 22979 - The table is model S20 MP Table size: 2200 x 2500 mm - The processing width on the machine X -Way is 6000 mm - Including 6 plates 5600 mm x 1850 mm
