Stock number: 2084-1087
Technical data
| Tractive force - max. 16 tonnes | |
| Effective stroke length max. 1250 mm | |
| Table width 400 mm | |
| Clearing speed 1...6.4 m/min | |
| More information on the product page |
Description of the
Tractive force - max. 16 tonnes
Effective stroke length max. 1250 mm
Table width 400 mm
Clearing speed 1...6.4 m/min
Return speed 19.5 m/min
Tool length - max. 1500 mm
Total power requirement 42 kW
Machine weight approx. 16 tonnes
- Specification: optional broaching right or left and simultaneously right and left
Effective stroke length max. 1250 mm
Table width 400 mm
Clearing speed 1...6.4 m/min
Return speed 19.5 m/min
Tool length - max. 1500 mm
Total power requirement 42 kW
Machine weight approx. 16 tonnes
- Specification: optional broaching right or left and simultaneously right and left
