Stock number: 2084-1108
Technical data
| Sheet thickness 0.5...5 mm | |
| Effective force 20 tonnes | |
| Travelling distance - x 1250 mm | |
| Travelling distance - y 750 mm | |
| More information on the product page |
Description of the
Sheet thickness 0.5...5 mm
Effective force 20 tonnes
Travelling distance - x 1250 mm
Travelling distance - y 750 mm
Punching speed 20 per min
Plunger stroke max. - infinitely variable 40 mm
Total power requirement 14 kW
Machine weight approx. 5 tonnes
- Traverse path in X-axis: 1250 mm (extendable to 2000 mm) - Traverse path in Y-axis: (extendable to 1000 mm) - Infinitely adjustable ram stroke up to: 40 mm - Punching example for steel Punching Ø 100 mm 1.5 mm Ø 50 mm 3.5 mm - Ø 16 mm 12.0 mm
Effective force 20 tonnes
Travelling distance - x 1250 mm
Travelling distance - y 750 mm
Punching speed 20 per min
Plunger stroke max. - infinitely variable 40 mm
Total power requirement 14 kW
Machine weight approx. 5 tonnes
- Traverse path in X-axis: 1250 mm (extendable to 2000 mm) - Traverse path in Y-axis: (extendable to 1000 mm) - Infinitely adjustable ram stroke up to: 40 mm - Punching example for steel Punching Ø 100 mm 1.5 mm Ø 50 mm 3.5 mm - Ø 16 mm 12.0 mm
