Stock number: 2084-1253
Technical data
| Workpiece diameter 2-10 mm | |
| Material | Stainless/heat-resistant steel / |
| Welding sequence | 15-20 bolts/min. at / mm |
| Welding area | M3-M10 or Ø 2-10 mm (M10 only with SOYER® HZ-1 bolt and SRM-Technology®) |
| More information on the product page | |
Description of the
Workpiece diameter 2-10 mm
Material: stainless/heat-resistant steel /
Welding sequence: 15-20 studs/min. at / mm
Welding range: M3-M10 or Ø 2-10 mm (M10 only with SOYER® HZ-1 studs and SRM-Technology®) Materials: Steel, stainless and heat-resistant steel (also brass and aluminium to some extent) Mains connection: 3 × 400 V, 50/60 Hz, fuse protection 16 A Welding current: max. 600 A, min. approx. 100 A (inverter technology) Weight: 16.5 kg Dimensions: (DxWxH)545 × 220 × 350 mm Ignition: Drawn arc ignition (DA), additionally SRM magnetic field technology
Material: stainless/heat-resistant steel /
Welding sequence: 15-20 studs/min. at / mm
Welding range: M3-M10 or Ø 2-10 mm (M10 only with SOYER® HZ-1 studs and SRM-Technology®) Materials: Steel, stainless and heat-resistant steel (also brass and aluminium to some extent) Mains connection: 3 × 400 V, 50/60 Hz, fuse protection 16 A Welding current: max. 600 A, min. approx. 100 A (inverter technology) Weight: 16.5 kg Dimensions: (DxWxH)545 × 220 × 350 mm Ignition: Drawn arc ignition (DA), additionally SRM magnetic field technology
